Description
MACHINE TYPE:
High-performance photodiode array detector for liquid chromatography (HPLC).
APPLICATION SECTOR:
Pharmaceutical, chemical, cosmetic, food, dietary, medical devices
FEATURES:
The Waters 996 Photodiode Array (PDA) Detector is designed to provide simultaneous spectral analysis over a wide range of wavelengths, enabling precise compound identification and peak purity assessment in chromatography. Its compact industrial design, along with a straightforward front panel featuring LED indicators for UV lamp monitoring, ensures ease of use. The precision optics and advanced electronics on dedicated PCBs offer high sensitivity and versatility in detecting analytes sensitive to ultraviolet and visible light.
TECHNICAL SPECIFICATIONS
Power Supply: 100-240 V (AC – Autorange)
Frequency: 50 / 60 Hz
Connection: Standard IEC (VDE) socket at the rear
Control Interface: Front rocker power switch (I/O) and remote control via management software
Status Indicators: LED “LAMP”: UV lamp on/off monitoring; LED “STATUS”: Diagnostic indicator of system operability
Detection System: Photodiode Array for multi-wavelength scanning
Certifications: Compliant with UL STD. 1262, CAN/CSA C22.2 NO. 151 Certificate (Laboratory Equipment), ETL Listed Mark
