Description
DESCRIPTION:
Machine for wrapping and packaging with cellophan film products cylindrical, square, rectangular and oval in various formats. The machine meets the needs for flexibility in packaging, product quality and investment. The unit packs, with any material, products with high aesthetic.
SECTORS OF USE:
Pharmaceutical, chemical, cosmetics, food, dietary, medical devices, manufacturing.
MAIN FEATURES:
The T20 automatic wrapping machine is suitable to wrap single products or to collate, with envelope style side folding or banding only. Possibility to use heatsealable films (PP, PVC, cellophane…) or kraft paper. Unwinding of wrapping material at 90° compared to product flow. Double reel holder unit positioned on operator side, it allows an easy replacement to new reel of wrapping material. High speed sealing and high products output. Solidly built machine. Easy access to all parts of the machine.
Year: 1996
TECHNICAL DATA
Length mm 1960
Width mm 1740
Height mm 1650
Weight Kg 350
Frequency Hz 50
Voltage Volt 380
Absorption W 3,5
Phases 3
Bundle dimension min. 25 x 10 x 60
Bundle dimension max. 120 x 60 x 300
Output 20-30 cycles/min
