Description
MACHINE TYPE:
Lateral channel blower
APPLICATION SECTOR:
Pharmaceutical, chemical, cosmetic, food, medical devices, manufacturing
FEATURES:
The Nilfisk A36XR2 lateral channel blower is a compact, high-efficiency industrial unit designed for powder transfer and integration into air capture systems. It is mounted on a robust vertical frame made of galvanized metal, integrating a Gardner Denver vacuum pump in the lower section and an integrated electrical panel with a control push-button and main safety switch in the upper section.
YEAR: 2018
TECHNICAL SPECIFICATIONS
Dimensions (L x W x H): 400 x 400 x 970 mm
Weight: 60 kg
Protection rating: IP 55
Markings and compliance: CE, EAC
Power supply voltage: 400 V (Three-phase, 3~)
Frequency: 50 Hz
Power consumption: 1.60 kW
Rated current: 4.30 A
Vacuum group manufacturer: Gardner Denver
Pump model: G-BH1 2BH1500-7AH26-ZN00
Group type: Compressor / Vacuum pump
Rotational speed (50 Hz): 2845 rpm
Pressure/vacuum performance (50 Hz): -200 mbar / +190 mbar
Motor thermal insulation class: TH.CL.F
Main switch: Rotary isolator (400V)
Controls: Key selector for mode management
Control panel: 6-element push-button panel with indicator lights (Run, Stop, Filter shaker/Cleaning, Electrical anomaly, Discharge valve, Manual operation)
