Description
DESCRIPTION:
Manual sizing taping machine, which seals the bottom and top of boxes with self-adhesive tape. The machine can be used by non-specialized operators as it requires very simple adjustment operations. The supply of the box is carried out by means of two motorized side belts, thus ensuring maximum uniformity of sliding. The result is a perfect alignment of the layers and therefore an optimal seal.
SECTORS OF USE:
Pharmaceutical, chemical, cosmetics, food, dietary, medical devices, manufacturing.
MAIN FEATURES:
Consistent durable case taper that manually adjusts to handle multiple box sizes. Sturdy structure in welded steel and powder coated finish. Side belt drive for narrow profile boxes. Dual masts and dual crossbars provide taping head stability. Taping Heads allow for low impact sealing that protects cases. Compression rollers squeeze flaps to together to create a tight centre seam. Emergency stop is positioned for fast and easy access. Seals up to 40 cases per minute, using tape widths from 36 mm to 48 mm.
Year of construction: 1998
TECHNICAL DATA
Lenght mm 1400
Width mm 1000
Height mm 1300
Weight Kg 100
Power W 260
Frequency Hz 50
Voltage Volt 380
Current A 1.4
PRODUCTION CHARACTERISTICS
Maximum box height mm 620
Maximum box width mm 546
N° of box /min 40
Minimum box height mm 121
Minimum box length mm 152
Minimum box width mm 114
Maximum box weight Kg 38.6
